Vehicle lifts by ceiling height – The right choice for your workshop
The available ceiling height largely determines which vehicle lift suits your workshop. Here you'll find all models filtered by height requirement – from low-lift solutions for halls under 2.20 metres to high-lift systems for workshops with over 3 metres of ceiling height.
How to use this filter:
- Perfectly matched to your hall: Filter directly by your ceiling height and immediately see which models fit your workshop – without lengthy searching.
- Don't waste space: Choose a model that optimally matches your spatial conditions – neither too large nor with unnecessarily large headroom above.
- Advice if in doubt: Not sure which ceiling height you really need? We'll help you determine the minimum height for your desired model.
OMCN 199/BETA | 4t | Base frame lift | Made in Italy
OMCN 199/DELTA | 3.5t | Base frame lift | Made in Italy
OMCN 199/RX " 5,5t " Spindle " Double articulated support arms
OMCN 199/WRX " 5.5t " Hydraulics " Double-jointed support arms
OMCN 550 " 2,5 t lifting capacity " Mobile " 400V
OMCN 718M - XL | 3.5t double scissor lift | above ground | long version
OMCN 719M - XL | 3.5t double scissor lift | underfloor | long version
OMCN 890 | Scissor Lift 6t | Flat Runways Surface 5100 mm
OMCN 890/I | Scissor Lift 6t | Flat Runways In-ground 5100 mm
OMCN 890/I+853/B | Scissor Lift 6t | Flat Runways In-ground 5500 mm
OMCN 890+853/B | Scissor Lift 6t | Flat Runways Surface 5500 mm
OMCN 891 | Scissor Lift 6t | Wheel Alignment Surface 5100 mm
OMCN 891/I | Scissor Lift 6t | Wheel Alignment In-ground 5100 mm
OMCN 891/I+853/B | Scissor Lift 6t | Wheel Alignment In-ground 5500 mm
OMCN 891+853/B | Scissor Lift 6t | Wheel Alignment Surface 5500 mm
Ceiling height and vehicle lifts: why the room height is decisive
Ceiling height is, alongside load capacity and vehicle type, one of the most important selection criteria for a vehicle lift. Don't underestimate the space requirements: the actual ceiling height needed results from the vehicle height plus the maximum lift height of the lift – plus a safety clearance of at least 30 to 50 cm to the ceiling.
How do I calculate the required ceiling height?
First determine the height of the tallest vehicle you want to lift. Add the maximum lift height of the lift plus a safety clearance of at least 30 cm to the ceiling. Example: a car at 1.50 m + 1.80 m lift height + 0.30 m safety clearance = a minimum ceiling height of 3.60 m. For lower halls, correspondingly low-lift models must be chosen.
Which ceiling height categories does hebebuehne24.de offer?
We carry lifts suitable for ceiling heights from 2.20 m, 2.70 m, 2.95 m, and for workshops with more than 3 m ceiling height. The filter lets you quickly find the right category for your workshop. For ceiling heights below 2.20 m we recommend personal consultation, as very few standard models are suitable for such low-clearance situations.
