Base Plate Floor Mounting 12cm Ravaglioli KPH35 & KPX35
Part Number: VSG.2CALL.901378
These support plates enable installation of the Ravaglioli 2-post lifts of the KPH35 and KPX35 series on workshop floors with low load-bearing capacity or insufficient concrete thickness. They distribute the point load of each column across a larger surface area, reducing the pressure on the floor. The set consists of two plates – one per column – and is designed for a minimum concrete thickness of 12 cm and a load capacity of 3.5 t per plate.
The base plate has a height of 15 mm and is designed for anchors with Ø 15 mm. Each plate requires 8 anchors (16 in total). Suitable anchors from our range: Art. No. 100-83 (15 mm x 143 mm).
Scope of delivery: 1 set (2 pieces). Anchors not included.
Compatible with the following Ravaglioli models
- KPH35
- KPH35M
- KPH35RM
- KPH35EVP
- KPX35
- KPX35E
- KPX35EV
- KPX35EEV
- KPX35LLE
