Adhesive anchor for lifting platforms with M12mm x 160mm length
Product number:
100-M12160
Product information "Adhesive anchor for lifting platforms with M12mm x 160mm length"
Adhesive anchor with extreme tensile strength for anchoring lifting platforms
- Ø 12 mm x 160 mm total length
- Attention: Drill hole Ø = 14 mm
- Extreme tensile strength due to chemical anchoring.
Applications of the adhesive anchor
This adhesive anchor can be used for all lifting platforms. Adhesive anchors are characterized by an even higher tensile strength than impact anchors.
Fits e.g. Ravaglioli KPX 337W or Zavagli Santi Eurolift Z-52/3S
- 2-post lifts
- 1-post lifts
- Scissor lifts
- 4-post lifts
- Parking lifts
- and many more
Application of this adhesive anchor
- A hole is drilled into the workshop floor with a Ø 14 mm drill bit. (110mm drill hole depth)
- The hole is cleaned extensively (brush, compressed air etc.)
- The cartridge of the anchor is pushed into the hole
- The threaded rod is driven into the hole and breaks the shell of the cartridge
- The liquid of the cartridge is distributed in the hole and forms around the threaded rod
- After the liquid has dried, the nut at the top of the threaded rod can be tightened to 40Nm.
What is needed?
- Ø 14mm drill bit
- 110 mm hole depth
Scope of delivery:
- 1x threaded rod M12
- 1x cartridge
- 1x nut
- 1x washer
